JP-5™ Roller Delayed 9mm Carbine

This is the revolution the PCC world has been waiting for.

In the world of Pistol Caliber Carbines, JP has become the industry standard with the unmatched reliability and accuracy of our GMR-15™ platform. Never ones to rest on our laurels, we’ve pushed PCC design to the edge with the state-of-the-art JP-5™. This 9mm carbine combines every advantage of its predecessor with the legendary function of the H&K MP5. The result is a PCC that is all things to all shooters.

In addition to a lighter overall weight, the roller-delayed operating system of the JP-5™ replicates the supreme recoil management of similar platforms. The result is a soft-shooting carbine with radically faster sight recovery and target indexing. As our Team JP shooter Josh Froelich puts it, “The JP-5™ shoots like a .223 not a 9mm carbine.” Combined with the unparalleled reliability our PCCs are known for, the JP-5™ is sure to be the go-to platform for competition, law enforcement and recreation.

Utilizing standard Glock 9mm magazines, the JP-5™ lower receiver features ambi. controls and maintains signature AR-15 ergonomics and height-over-bore. The operating system also accepts most MP5 aftermarket components. The JP-5™ is tunable in both the Silent Captured Spring buffer system and lock piece to accommodate suppressed use as well as varying barrel length and ammunition.

The JP-5™ is available with either the standard top-charge upper receiver or the PSC-5™ dual-charge upper with both top- and side-charge handles. Complete carbines are available for order now, or build your a JP-5™ just as you want it and save with our JP-5™ Chassis builder.

---

JP-5™ Features:

• Proven, unmatched reliability
• Superior roller-delay recoil management
• Faster sight recovery and target indexing
• Light weight
• Glock 9mm magazine compatible
• Steel-reinforced billet receiver set
• Adjustable/interchangeable lock pieces for custom configuration tuning
• JP Silent Captured Spring System
• AR-15 ergonomics and height-over-bore
• Compatibility with AR-15 stock, grips and accessories
• Compatibility with multiple MP5 operating system components

---

Base Carbine Specifications:

Receiver:	Machined-from-billet JP-5™ G940 receiver set
Receiver Finish:	Matte black
Barrel:	JP Supermatch™ air-gauged, button-rifled, cryogenically treated barrel w/ fluted chamber
Barrel Finish:	Polished stainless or Black Teflon®
Muzzle Treatment:	JP tactical or competition compensator
Caliber:	9mm
Buttstock:	Hogue Overmolded or Mission First Tactical
Grip:	Hogue pistol grip
Hand Guard:	JP MK III Hand Guard System
Operating System:	Roller delay BCG with JP 9mm Silent Captured Spring
Trigger:	JP Enhanced Reliability Fire Control Package with a weight of 3.5-4 lbs.
Accessories:	JP accessory pack including operator’s manual, one magazine*, and more

JP-5™ Chassis

Starting with an AR base gives the JP-5™ most of the customizeability that makes the MSR so popular. To help you get into the JP-5™ just like you want it, we offer the JP-5™ Chassis to give you everything you need with nothing you don't while clocking in at a more affordable price.

The JP-5™ Chassis eliminates the need to swap out factory parts and is built to the your specification to include only what you need, and nothing you don’t want. Each chassis package includes all the proprietary components of our revolutionary roller-delayed 9mm platform:

1. JP-5™ lower receiver
2. Choice of upper receiver (standard top-charge or dual-charge PSC-5™)
3. Choice of barrel with finish
4. JP-5™ operating system with bolt carrier group and Silent Captured Spring
5. All proprietary components and small parts

Beyond that, the JP-5™ is compatible with most all standard AR 9mm muzzle treatments, hand guards, triggers, buttstocks and grips. Like our Semi-Auto Chassis System, you can on any JP-brand components to your build at 10% off at time of ordering.

JP-5™ Chassis
	Base Price: $2465 Go to Rifle Builder

JP Rifle Builder | JP-5™ Custom Builds

JP-5™ Rifle
	Base Price: $3199 Go to Rifle Builder

JP-5™ (9mm) Pistol or SBR
	Base Price: $3199 Go to Rifle Builder

JP-5™ Upper Assembly
	Base Price: $1899 Go to Rifle Builder

JP-5™ Chassis
	Base Price: $2465 Go to Rifle Builder
